 J Micro Technology is a worldwide supplier of probe station and text fixtures for advanced semiconductor devices and packaging products. We supply the necessary accessories to bring the precision of coaxial/coplanar microwave probes to non-coplanar test structures through precision low cost thin film network (TFN) "adapters,” ProbePoints and affordable microprobing test fixtures and probe stations. We are breaking unprecedented barriers in performance and compatibility in the industry to provide faster, more accurate testing using the latest technology.

We have provided engineers and researchers in government agencies, universities and materials research industries with state-of-the-art equipment and innovative solutions since 1993. Our products produce measurable, consistent results with delicate, valuable materials and remove undesirable variation and uncertainty. Leverage affordable, top-quality engineering tools in your tests to reach successful developments and actionable information faster, even working with tight deadlines and budgets.

Equip your workspace with cutting-edge technology anywhere in the world with a single click. Browse our extensive selections of ProbePoint stations and accessories to find the right size, device and fitting for your function. Our stations are ideal research and teaching tools as well as key sources for production and development. We work closely with clients to ensure top performance and compatibility, as well as quick, reliable shipping, and we are happy to answer any questions you may have.

Contact our experts for any inquiries on our products, shipping or service.

  • Microwave Test Accessories - Thermal chuck adapters, DC needle positioners and needle probes, vision capture systems Calibration Kits, Picoprobes (GGB)
    • Test Cables - Metrology grade cables for microwave microprobe testing
  • ProbePoint - Precise thin film networks (TFN) adapters for Coplanar waveguide to microstrip circuits and MMIC subassemblies
    • ProbePoint adapter substrates for DevicesCoplanar waveguide to microstrip circuits ( 5 mil, 10 mil, 15 mil versions)
    • ProbePoint adapter substrates for MMICsCoplanar waveguide to microstrip circuits with bond wire compensation ( 5 mil version)
    • ProbePoint microstrip transmission line substrates - Precise microstrip circuits for test of packages and multichip MMIC interconnect.
    • Calibrations Substrates - for direct calibration of ProbePoint Adapter Substrates and coplanar picoprobe (GGB)
    • OSLT Calibrations Kits - "Surrogate Package" calibration standards for surface mount package test fixtures.

Laboratory Microprobe Station

affordable microprobe station prober shielded guarded chuck cox triax probes MEMS nanotechnology sensors thin film test

LMS-2709
Data Sheet

An Affordable RF/Microwave and DC/Low Frequency probe station
for research and teaching laboratories
Versatile Platform for Small Lot Production Test
LMS-2709 has a translation stage with 1" x-y travel and z-lift
standard 2" square vacuum chuck
2 or more magnetic mount ball bearing 0.5" travel positioners,
compatible with GGB ECP18, Model 40, Model 7 and Model 10 probes in addition to other Shielded, Kelvin, Triaxial probes,
7X-30X Stereo Zoom binocular or trinocular microscope
LED light ring illuminator
included vacuum pump
Shielded Chuck
included foam lined storage container.
In excess of 4 optional  magnetic mount positioners can be used on the base platten
for four sided probing of test devices to >40 gHz
Optional: DC Needle holder and needles coax or triax probes and shielded guarded chuck
Larger Platen for additional positioners available
Optional: Temperature controlled chuck




JR-2745 Manual Probe Station

Jr-2736 Manual Probe Station for RF Microwave MEMS Nanoelectronic Semiconductor electrical test and probe

A affordable manual probe station for testing high speed, microwave and RF semiconductors
with wafer sizes up to 200mm (8")
Magnetic mount or 'bolt on' microwave positioners
4.5" probe card adapter available
South position insert plate available for NSEW probe location


J microTechnology probe stations offer a cost effective platform
for dedicated test systems that require short cables
such as the Pulsed IV Test System "DiVA" from Accent Optical Technologies
or the Load Pull  Test Modules from Maury Microwave
DiVA 225 Pulsed IV Test System with J microTechnology (J micro) Manual Probe Station and Controlled impedance GGB Industries probes (Model ECP) probe strained silicon GaAs SiC or other high power semiconductor devices

Optional Mezzanine Shelf puts the DiVA Pulsed IV Test System
within 4" cable distance to the probes for enhanced test performance.
Mezzanine Shelf and 4" cables available from J microTechnology.

We want to serve our customers by making their tasks easier and more productive.
